Model: LS-BALL-P2.5-D4

Applications:

  • Museums & Planetariums: Present astronomical content, earth sciences, or immersive educational visuals with full surround views that captivate audiences.
  • Corporate Spaces: Make a bold statement in lobbies, exhibition areas, or trade shows with a spherical display that demonstrates cutting-edge technology and creativity.
  • Retail & Showrooms: Capture customer attention with high-impact advertising, product demos, and engaging brand content presented in a unique, three-dimensional format.

Key Features:

  • High Resolution P2.5 Pixel Pitch: With a 2.5mm pixel pitch, this spherical LED display offers ultra-clear images, ensuring crisp content even when viewed from close distances.
  • 360-Degree Viewing: Perfectly spherical, the LS-BALL-P2.5-D4 allows viewers to experience visuals from all angles, creating a unique panoramic experience.
  • Customizable Content Presentation: The sphere’s design supports dynamic content that can be adjusted to fit the curvature of the screen, making it ideal for presenting anything from immersive visuals to detailed product demonstrations.
  • Seamless Integration: This display integrates easily into a variety of spaces, making it suitable for both permanent installations and temporary exhibits.
  • Versatile Applications: Ideal for museums, planetariums, science exhibitions, corporate lobbies, retail spaces, and more. The spherical design is particularly effective for interactive storytelling and educational environments.

Specification:

Parameter Unit Value
Pitch mm 2.5
Brightness nits 1000
Color temperature deg. K 6500
Viewing angle – Horizontal (50% brightness) deg. 140(-70 ~ +70)
Viewing angle – Vertical (50% brightness) deg. 140(-70 ~ +70)
Net Weight kg 3200
Diameter mm 4000
Panel area sq. m. 50.27
Resolution Pixel 4992*2512
Operating temperature range deg. C -30 to +60
Material   Steel
Ingress protection (front/rear)   IP23
Humidity operating RH 10% ~ 90%
Pixel type and configuration R/G/B 3in1 SMD
Surface protection (Optional) GOB
Dot per sq. meter   160000
LED per sq. meter   160000
Recommended minimum viewing distance m 1.9
Recommended best viewing distance m 3~200
Colors    281 trillion
Grey scale (linear) Levels 65536 levels per color
Brightness control Levels 100
Contrast ratio   3000:1
Processing depth bit 16
Video frame rate Hertz 60
Display refresh rate Hertz 3840
Input voltage (nominal) VAC 110 to 240
Input power frequency Hertz 50 to 60
Input power (max) Watts/set 30000
Input power (typical) Watts/set 12000
Lifetime (50% brightness) Hours ≥100000
Red wavelength (dominant) nm 620~625
Green wavelength (dominant) nm 525~530
Blue wavelength (dominant) nm 470~475
Multimedia data format   DVI,MPG,AVI,WMV,RM etc.
Control way   Synchronous
Data interconnection   UTP Cat 5
Mounting system   Hanging & Stand on ground
Package   Fumigation wooden case / Flight Case

LED Sphere Videos:
