P4.8 LED Ball ( LED Sphere ) Diameter 2m

Model: LS-BALL-P4.8-D2

Application: Indoor Shopping mall, Bar, Club or Stage Use

Enquire us

Feature:

* Pitch 4.8mm
* Creative Design
* Easy to maintain
* Indoor Application
* Diameter=2meter

Specification:

Parameter Unit Value
Pitch mm 4.8
Brightness nits 1200
Color temperature deg. K 6500
Viewing angle – Horizontal (50% brightness) deg. 140(-70 ~ +70)
Viewing angle – Vertical (50% brightness) deg. 140(-70 ~ +70)
Net Weight kg 160
Diameter mm 2000
Panel area sq. m. 12.56
Resolution Pixel 1280*768
Operating temperature range deg. C -30 to +60
Material Steel
Ingress protection (front/rear) IP23
Humidity operating RH 10% ~ 90%
Pixel type and configuration R/G/B 3in1 SMD
Dot per sq. meter 43402
LED per sq. meter 43402
Recommended minimum viewing distance m 3.6
Recommended best viewing distance m 4~200
Colors 281 trillion
Grey scale (linear) Levels 65536 levels per color
Brightness control Levels 100
Contrast ratio 1000:1
Processing depth bit 16
Video frame rate Hertz 60
Display refresh rate Hertz 600
Input voltage (nominal) VAC 110 to 240
Input power frequency Hertz 50 to 60
Input power (max) Watts/set 8000
Input power (typical) Watts/set 3200
Lifetime (50% brightness) Hours ≥100000
Red wavelength (dominant) nm 620~625
Green wavelength (dominant) nm 525~530
Blue wavelength (dominant) nm 470~475
Multimedia data format DVI,MPG,AVI,WMV,RM etc.
Control way Synchronous
Data interconnection UTP Cat 5
Mounting system Hanging & Stand on ground
Package Fumigation wooden case
Volume size m 2.2*2.2*2.6m
Gross weight kg 220
Volume size CBM 12.584



Data Sheet:

LS-BALL-P4.8-D2 (12.56sqm).pdf
