Parameter

Unit

Value

Pitch

mm

1.5

Brightness

nits

800

Color temperature

deg. K

6500

Viewing angle – Horizontal (50% brightness)

deg.

140(-70 ~ +70)

Viewing angle – Vertical (50% brightness)

deg.

140(-70 ~ +70)

Diameter

mm

1.5

Panel area

sq. m.

7.07

Resolution

Pixel

3072*1536

Operating temperature range

deg. C

-30 to +60

Material

Steel

Ingress protection (front/rear)

IP23

Humidity operating

RH

10% ~ 90%

Pixel type and configuration

R/G/B

3in1 SMD

Dot per sq. meter

423855

LED per sq. meter

423855

Recommended minimum viewing distance

m

1

Recommended best viewing distance

m

1.2~200

Colors

281 trillion

Grey scale (linear)

Levels

65536 levels per color

Brightness control

Levels

100

Contrast ratio

3000:1

Processing depth

bit

16

Video frame rate

Hertz

60

Display refresh rate

Hertz

3840

Input voltage (nominal)

VAC

110 to 240

Input power frequency

Hertz

50 to 60

Input power (max)

Watts/sqm

600

Input power (typical)

Watts/sqm

240

Lifetime (50% brightness)

Hours

≥100000

Red wavelength (dominant)

nm

620~625

Green wavelength (dominant)

nm

525~530

Blue wavelength (dominant)

nm

470~475

Multimedia data format

DVI,MPG,AVI,WMV,RM etc.

Control way

Synchronous / Asynchronous

Data interconnection

UTP Cat 5

Mounting system

Hanging& Stand on ground

Package

Fumigation wooden case
