P2 Mirror Poster LED Display

Model: LS-MP2-0.64mx1.92m

Application: Indoor Advertising

Enquiry us


For indoor application;
Pitch 2mm;
Ground Stand & Wall hanging;
Wide viewing angle;
Service acess: Front & Back;
PC software or Android App or IOS App control


Parameter Unit Value
Pitch mm 2
Brightness nits 1,000
Color temperature deg. K 6,500
Viewing angle – Horizontal (50% brightness) deg. 140(-70 ~ +70)
Viewing angle – Vertical (50% brightness) deg. 140(-70 ~ +70)
Weight kg 33
LED area mm 640*1,920
Frame size mm 652*1,932*35
Out frame Cover PMMA panel
LED area sq. m. 1.2288
Panel material Aluminum alloy
Panel protection IP22/43
Service access Front & Back service
Operating temperature range deg. C -30 to +60
Humidity operating RH 10% ~ 90%
Pixel type and configuration R/G/B Indoor 3in1 SMD
Resolution per panel 320*960
Dot per panel 307,200
Dot per sq. meter 250,000
LED per sq. meter 250,000
Recommended minimum viewing distance m 1.5
Recommended best viewing distance m 2~50
Colors 281 trillion
Grey scale (linear) Levels 65,536 levels per color
Brightness control Levels 100
Contrast ratio 2,000:1
Processing depth bit 16
Video frame rate Hertz 60
Display refresh rate Hertz 600
Input voltage (nominal) VAC 110 to 240
Input power frequency Hertz 50 to 60
Input power (max) Watts / set. 700
Input power (typical) Watts / set. 280
Lifetime (50% brightness) Hours ≥100,000
Red wavelength (dominant) nm 620~625
Green wavelength (dominant) nm 520~525
Blue wavelength (dominant) nm 470~475
Control system Full color asynchronous
Data interconnection Wifi / USB / HDMI
Software PC software or Android App or IOS App
Mounting system Stand on ground




Project Case:
