P10 Outdoor Module Front Service LED Display

Model: LS-O-P10-SMD-MF-0.96mx0.96m-IP65

Application: SMD LED Display for fixed installation

Enquire us

Feature:

For Outdoor fixed installation application;
SMD LED Display;
Weatherproof to IP65/65 standards;
High resolution images and long lifetime;
Easily configured for various size and aspect ratios;
Wide viewing angle;
Brightness from 6000 nits onwards.
Service access: Module front service

Specification:

Parameter Unit Value
Pitch mm 10
Brightness nits 5000
Color temperature deg. K 6500
Viewing angle – Horizontal (50% brightness) deg. 140(-70 ~ +70)
Viewing angle – Vertical (50% brightness) deg. 140(-70 ~ +70)
Panel weight kg 40
Panel width mm 960
Panel height mm 960
Panel depth mm 155
Panel area sq. m. 0.9216
Panel material Epoxy paint coated Cold rolled steel
Service access Module front service
Ingress protection (front/rear) IP IP65/IP65
Operating temperature range deg. C -30 to +60
Humidity operating RH 10% ~ 90%
Pixel type and configuration R/G/B Outdoor 3in1 SMD
Resolution per panel 96*96
Dot per panel 9216
Dot per sq. meter 10000
LED per sq. meter 10000
Recommended minimum viewing distance m 7.6
Recommended best viewing distance m 8~100
Colors 281 Trillion
Grey scale (linear) Levels 65536 levels per color
Brightness control Levels 100
Contrast ratio 1000:1
Processing depth bit 16
Video frame rate Hertz 60
Display refresh rate Hertz 180~3000
Input voltage (nominal) VAC 110 to 240
Input power frequency Hertz 50 to 60
Input power (max) Watts / panel 800
Input power (typical) Watts / panel 320
Lifetime (50% brightness) Hours ≥100000
Red wavelength (dominant) nm 620~625
Green wavelength (dominant) nm 525~530
Blue wavelength (dominant) nm 470~475
Multimedia data format DVI,MPG,AVI,WMV,RM etc.
Data interconnection UTP Cat 5/Optical Fiber
Mounting system Fixed with 4pcs M10 bolts
Controller Linsn/NOVA


Download:

LS-O-P10-SMD-MF-0.96mx0.96m-IP65.pdf
