Indoor P2.5 Die-cast LED Display

Model: LS-DI-P2.5-0.64mx0.64m

Application: Indoor Rental or Fixed Installation

Enquiry us

Feature:

* Light weight: one person is able to carry one cabinet easily, very convenient in assembly and transport.
* Urtra Thin: Depth of the cabinet is 90mm only,Save space for both the application site and transportation.
* Precise Die-cast Aluminum Magnesium Alloy Cabinet: seamless assembly;
* Easy to maintain;
* Removable center cabinet.

Specification:

ParameterUnitValue
Pitchmm2.5
Brightnessnits1,200
Color temperaturedeg. K6,500
Viewing angle – Horizontal (50% brightness)deg.140(-70 ~ +70)
Viewing angle – Vertical (50% brightness)deg.140(-70 ~ +70)
Panel weightkg12
Panel widthmm640
Panel heightmm640
Panel depthmm90
Panel areasq. m.0.4096
Panel material Epoxy paint coated Aluminum
Panel Mode Die-Cast rental
Operating temperature rangedeg. C-20 to +60
Humidity operatingRH10% ~ 60%
Pixel type and configurationR/G/B3-in-1 SMD
Resolution per panel 256×256
Dot per panel 65,536
Dot per sq. meter 160,000
LED per sq. meter 160,000
Recommended minimum viewing distancem1.9
Recommended best viewing distancem2~50
Colors 281 Trillion
Grey scale (linear)Levels65,536
Brightness controlLevels256
Contrast ratio 2,000:1
Processing depthbit16
Video frame rateHertz60
Display refresh rateHertz180~3,000
Input voltage (nominal)VAC110 to 240
Input power frequencyHertz50 to 60
Input power (max)Watts / panel.400
Input power (typical)Watts / panel.160
Lifetime (50% brightness)Hours≥100,000
Red wavelength (dominant)nm620~625
Green wavelength (dominant)nm520~525
Blue wavelength (dominant)nm470~475
Multimedia data format DVI,MPG,AVI,WMV,RM etc.
Data interconnection UTP Cat 5/Optical Fiber
Mounting system Hanging/Fixed

Data Sheet:

LS-DI-P2.5-0.64mx0.64m.pdf
