P6 Indoor Die-cast Rental LED Display

Model: LS-DI-P6-0.576mx0.576m

Application: Indoor Fixed Installation


  • Light weight: one person is able to carry one cabinet easily, very convenient in assembly and transport.
  • Urtra Thin: Depth of the cabinet is 90mm only,Save space for both the application site and transportation.
  • Precise Die-cast Aluminum Cabinet: seamless assembly;
  • Easy to maintain;
  • Removable center cabinet.


Color temperaturedeg. K6,500
Viewing angle – Horizontal (50% brightness)deg.140(-70 ~ +70)
Viewing angle – Vertical (50% brightness)deg.140(-70 ~ +70)
Panel weightkg7.3
Panel widthmm576
Panel heightmm576
Panel depthmm90
Panel areasq. m.0.332
Panel material Magnesium aluminum alloy
Panel Mode Die-Cast rental
Operating temperature rangedeg. C-30 to +60
Humidity operatingRH10% ~ 90%
Pixel type and configurationR/G/B3 in 1 SMD
Resolution per panel 96×96
Dot per panel 9,216
Dot per sq. meter 27,778
LED per sq. meter 27,778
Recommended minimum viewing distancem4.5
Recommended best viewing distancem6~18
Colors 281 Trillion
Grey scale (linear)Levels65,536 levels per color
Brightness controlLevels256
Contrast ratio 1,000:1
Processing depthbit16
Video frame rateHertz60
Display refresh rateHertz180~3,000
Input voltage (nominal)VAC110 to 240
Input power frequencyHertz50 to 60
Input power (max)Watts /panel200
Input power (typical)Watts /panel80
Lifetime (50% brightness)Hours≥100,000
Red wavelength (dominant)nm620~625
Green wavelength (dominant)nm520~525
Blue wavelength (dominant)nm470~475
Multimedia data format DVI,MPG,AVI,WMV,RM etc.
Data interconnection UTP Cat 5/Optical Fiber
Mounting system Hanging / Fixed
