7 segment Gas Price LED Display C

Application: Outdoor Gas Price LED Display

Enquire us

Feature:

  1. For Outdoor Gas price station to show gas price;
  2. Weatherproof to IP65 standards;
  3. Wide viewing angle;
  4. Brightness from 3000nit onwards.
  5. Color option: red/green/blue/white;
  6. 15inch digital height;(option 8inch,10inch,12inch,20inch)
  7. RF wireless communication, RF remote controller;

Specification:

Parameter Unit Value
Brightness nits 3,000
Viewing angle (50% brightness) deg. 60(+30/-30)
Panel weight kg 12
Panel width mm 1,280
Panel height mm 480
Panel depth mm 70
Panel material Epoxy paint coated Cold rolled steel
Ingress protection (front/rear) IP IP65/IP43
Operating temperature range deg. C -30 to +60
Humidity operating RH 10% ~ 90%
Color Red/Yellow/Green/ White
Digital design 7 segment
LED Qty each segment Pcs 35
LED Qty each digital pcs 245
Brightness control Levels 8
Contrast ratio 1,000:1
Input voltage (nominal) VAC 110 to 240
Input power frequency Hertz 50 to 60
Input power (max) Watts / cabinet 30(R/Y), 50(G/W)
Lifetime (50% brightness) Hours ≥100,000
Red wavelength (dominant) nm 620~625
Yellow wavelength (dominant) nm 590~595
Green wavelength (dominant) nm 525~530
White wavelength (dominant) K 6000
Data interconnection UTP Cat 5
Communiation RF
Mounting system Fixed with 4pcs M10 bolts
Certification CE,ROHS
