P8 Indoor LED Display

Model: LS-I-P8-1.024mx0.768m

Application: Indoor Fixed Installation

Enquire us

Feature:

Pitch 8mm;
LED Density: 15,625pixel/sqm;
For indoor fixed installation application;
True and natural color, perfect displaying effect;
High brightness & high resolution;
Seamless panels with excellent flatness;
High contrast ratio which ensures vivid images;
Low power consumption, environmentally friendly;
Wide viewing angle: 140 degree both horizontal and vertical;

Specification:

Parameter Unit Value
Pitch mm 8
Brightness nits 1,000
Color temperature deg. K 6,500
Viewing angle – Horizontal (50% brightness) deg. 140(-70 ~ +70)
Viewing angle – Vertical (50% brightness) deg. 140(-70 ~ +70)
Panel weight kg 45
Panel width mm 1,024
Panel height mm 768
Panel depth mm 150
Panel area sq. m. 0.7864
Panel material Epoxy paint coated Cold rolled steel
Operating temperature range deg. C -30 to +60
Humidity operating RH 10% ~ 90%
Pixel type and configuration R/G/B 3in1 SMD
Resolution per panel 128×96
Dot per panel 12,288
Dot per sq. meter 15,625
LED per sq. meter 15,625
Recommended minimum viewing distance m 8
Recommended best viewing distance m 10~27
Colors 281 Trillion
Grey scale (linear) Levels 65,536 levels per color
Brightness control Levels 100
Contrast ratio 1,000:1
Processing depth bit 16
Video frame rate Hertz 60
Display refresh rate Hertz 180~3,000
Input voltage (nominal) VAC 110 to 240
Input power frequency Hertz 50 to 60
Input power (max) Watts / panel 400
Input power (typical) Watts / panel 160
Lifetime (50% brightness) Hours ≥100,000
Red wavelength (dominant) nm 620~625
Green wavelength (dominant) nm 520~525
Blue wavelength (dominant) nm 470~475
Multimedia data format DVI,MPG,AVI,WMV,RM etc.
Data interconnection UTP Cat 5/Optical Fiber
Mounting system Fixed with 4pcs M10 bolts



Download:

LS-I-P8-1.024mx0.768m.pdf
